Wafer

SrTiO₃ Wafer (Strontium Titanate Wafer)

High-quality insulating perovskite oxide substrate for epitaxial growth and advanced oxide thin film applications

Enquire about this product ↗
Prefer a quick conversation?WhatsApp us +65 8176 3868

SrTiO₃ Wafer (Strontium Titanate Wafer) Specifications

Overview

SrTiO₃ (STO) wafer is a high-quality single crystal perovskite oxide substrate widely used for epitaxial growth of complex oxide thin films and functional materials. As an intrinsic (undoped) material, STO exhibits excellent insulating properties, making it an ideal substrate for applications requiring electrical isolation. With its well-matched lattice structure and high crystalline quality, SrTiO₃ is commonly used in PLD, MBE, and sputtering processes. It is one of the most widely used substrates in oxide electronics, superconducting materials, and ferroelectric research.

Key Features
  • Intrinsic insulating substrate (no doping)
  • Excellent lattice matching with perovskite oxides
  • High crystal quality for epitaxial growth
  • Suitable for PLD, MBE, and sputtering deposition
  • Stable cubic structure
  • Smooth surface with epi-ready finish
Material property
  • Product: SrTiO₃ Wafer
  • Crystal structure: Cubic (Perovskite)
  • Lattice constant: a = 3.905 Å
  • Density: 5.12 g/cm3
  • Melting point: 2080 °C
  • Growth Method: CZ
Dimension
  • 5 × 5 × 0.5 mm
  • 10 × 10 × 0.5 mm
  • Other sizes customizable
Orientation
<100> / <110> /<111>
Polishing
  • As-cut / Single side / double side epi-polished
  • Surface roughness: < 0.5 nm
Applications
  • Oxide thin film epitaxy (PLD / MBE / sputtering)
  • High-temperature superconductors (HTS)
  • Ferroelectric and dielectric materials
  • Thin film research and device fabrication
  • Interface physics and 2DEG studies
  • Buffer layer substrate for complex oxides
Why Choose STO Wafer
  • Industry-standard substrate for perovskite oxides
  • Excellent lattice compatibility
  • High surface quality for epitaxial growth
  • Reliable and widely validated in research
Customization Options
  • Orientation & off-cut
  • Thickness & size
  • Surface finish (SSP / DSP / Epi-ready)
  • Research-grade / device-grade
